SW Series Handwheel Gearbox Operator

SW Series Handwheel Gearbox Operator

Our SW Series hand wheel gearbox are special designed of gearbox cover can support the limit switch bracket, easy to amount the limit switch directly without any accessories. This series gearbox can control 90 degree rotary valves, such as butterfly valve, ball valve and plug valve and so on. The aluminum alloy material body after static electricity powder coating has an excellent appearance, strong adhesion/mechanical property and anti-corrosion/wear resistance.

- The output torque range:180-2800NM
- ISO 5211 direct mount patterns

- Filled with special lubricant before leaving the factory.

- Weatherproof is IP 65.
- 5 degree angle adjusting
- Optional accessory include the position indicate or core joint etc
- Limit switch model selection please reference the page of ALS series
