Liquid Filled Pressure Gauge
YTN-Series liquid filled pressure gauge fill damping fluid(silicone oil,glycereol) in the gauge snd other measures to ensure that it has excellent fuction of impact resistance and aseiamatic .So it is safe and reliable with stable performance and long useful-life it is apply to mechanical.chemical.metallury.mine electrical.measure the pressure of medium is noe corrosive for copper and alday.if measure the pressure of high corrosive medium ,all material of pressure gauge must be stainless stell.
Liquid Filled Pressure Gauge Working conditions
1)Ambient temperature:-40¡æ¡«+70¡æ.
2)Working pressure hydrostatic pressure measurement value of the maximum pressure of 1 / 3 to 3 / 4. Pressure fluctuations are measured under the condition of pressure value should be in the upper 1 / 3 to 2 / 3.
3)Relative humidity¡Ü80%.
4)Working vibration frequency ¡Ü25HZ,¡Ü1mm medium vibration.
5)The instrument must be installed vertically,installation and disassembly are not allowed to use the wrench enclosure.
